The double shaft shredder is suitable for recycleing wide range of materials . it is an ideal machine for plastic ,paper ,fiber ,rubber ,organic waste and a wide variety of materials .this is a quality and reliable equipment in recycling business.
As per our customer’s requirements ,such as the input size of the material ,capacity and the final output size etc, we could work out a suitable proposal for our clients . After being shredded by the machine ,the output material could be used directly or go into the next step of size reduction . Applications
1. A variety of hollow containers: Plastic beverage cans, plastic buckets, iron cans,packing boxes.
2. Waste household appliances: TV, washing machine, refrigerator shell
3. Pipe: Large pipes, pipe fittings, PE pipe
4. Waste template: wooden pallets, plastic pallets,truck pallet
5. waste tires: car tires, truck tires
6. scrap metal: car shell, Aluminum die casting scraps, engine shell, gear boxes ,lead as well as the steel plate with less than 5mm thickness.
7. The food waste, garbage, animal carcasses, RDF derivatives, medical waste, biological straw, garden garbage
Working principle
The basic principles of metal grinder with a motor driven wind wheel extrusion, the core principle is to use the basic principles of a hammer, and the discharge port with a filter-type conveyors, high-speed high-torque motor driven rotor hammer on the host take turns hitting into the cavity of the substance to be broken, the space between the liner and the hammer through the formation of the material to be broken torn into conforming to specifications detritus. Metal grinder crusher according to the working conditions, the system can be divided into dry and wet systems and sub-humid systems.
Features of Double shaft film plastic shredder
1. The combination structural frame made from ultra thick plate by precision machining , strong wide-angle rotating shaft hexagonal columns,large diameter solid feeding hopper,so you can be assured to put in large raw materials ;
2. A unique rotary knife is designed in terms of thickness , shape and arrangement of the order, with strong cut ability, sharp blade , high broken efficiency;The knife tool is made from special alloy steel ,solid and durable.it can get very high efficiency and high capacity
3. Low speed, low noise, less dust ;
4. Advanced structure and drive design, strong crushing capacity;
5. High and steady quality, long duration;
6. Program control, over-load protection, automatic reset;
Features
1. The combination structural frame made from ultra thick plate by precision machining , strong wide-angle rotating shaft hexagonal columns,large diameter solid feeding hopper,so you can be assured to put in large raw materials ;
2. A unique rotary knife is designed in terms of thickness , shape and arrangement of the order, with strong cut ability, sharp blade , high broken efficiency;The knife tool is made from special alloy steel ,solid and durable.it can get very high efficiency and high capacity
3. Low speed, low noise, less dust ;
4. Advanced structure and drive design, strong crushing capacity;
5. High and steady quality, long duration;
6. Program control, over-load protection, automatic reset;
Technical Parameters:
Model
| Capacity(T/H) | Power(Kw) |
| TCMS-600 | 0.5-2 | 22 |
| TCMS-800 | 1-3 | 30 |
| TCMS-1000 | 2-5 | 37 |
| TCMS-1200 | 3-8 | 44 |
| TCMS-1600 | 5-10 | 74 |
| TCMS-2000 | 10-15 | 90 |
| TCMS-2200 | 15-20 | 110 |
| TCMS-2400 | 20-50 | 180 |
