Introduction
Pellet machine is suitable for making straw pellet, sawdust pellet and feed pellet. It is multifunctional.The materials can be grain stalk,grass,sawdust,corn straw,wheat straw,corn,grain,wheat
and so on.be used for feeding animals and poultries.such as chicken, pigeon,pig, cow,goat, rabbit, dog, cat and so on.
Features:
1. Inlet structure using curling
2. Competitive price with good quality
3. Low energy consumption and less manpower
4. Durable spare parts
5. Simple and automatic operation
6. Easy maintenance
7. Perfect technical design with less labor
8. Stable and durable equipment function
Structure:
This feed pellet machine has a compact structure, beautiful appearance, large discharge diameter features. Flat die moving plate design,
suitable for feed grain, high yield,low power consumption, reliable and easy to use, stable work performance advantages.
Working principle:
This machine consists of motor, gear shaft, flat die, roller, feed hopper, cutter, several parts of the hopper.
When it worked, the die turn around rather than the roller.
Under these two parts pressure, pellets will be press out, you can adjust the cutter’s position to change the length of final products.
Technical Parameters
|
Model |
Capacity |
Main motor
（kw） |
Weight
（kg） |
Size(m)
|
|
TCP-120 |
70-100kg/h |
2.2kw |
80/100 |
0.75*0.32*0.68 |
|
TCP-150 |
90-120kg/h |
4kw |
95/100 |
0.8*0.45*0.7 |
|
TCP-200 |
200-300kg/h |
7.5kw |
200/230 |
1.65*0.82*1.2 |
|
TCP-230 |
300-400kg/h |
11kw |
290/320 |
1.05*0.48*0.93 |
|
TCP-260 |
400-600kg/h |
15kw |
320/360 |
1.18*0.54*1 |
|
TCP-300 |
600-800kg/h |
22kw |
350/380 |
1.24*0.54*0.95 |
|
TCP-400 |
800-1100kg/h |
30kw |
550/585 |
1.14*0.47*0.97 |
Any change of technical data shall not be advised additionally. We will supply you good price
